Salvage & Towage

Fleet Details

BUILT:

"TAI O"	--- April 2012
"YAM O"	--- June 2012
Builder:	--- Cheoy Lee Shipyards Ltd. Hong Kong
Designer:	--- Robert Allan Ltd., Canada

CLASSIFICATION:

Lloyd’s Register

✠100A1 Tug

✠LMC Unrestricted Service

FLAG:

Hong Kong

CALL SIGN:

"Tai O"	--- VRJW7
"YAM O"	--- VRJW8

OFFICAL NO.:

"Tai O"	--- HK - 3369
"YAM O"	--- HK - 3370

IMO NO.:

"Tai O"	--- HK - 9617002
"YAM O"	--- HK - 9617014

DIMENSIONS:

Length, overall: 30.00 m
Beam moulded: 11.60 m
Depth, moulded: 5.38 m
Draft, Maximum: 5.64 m
GRT: 481T
NRT: 144T

MACHINERY:

Main Engines:
2 x Niigata 6L28HX, total 5,000 BHP at 750 rpm, driving fixed pitch Kaplan propellers in 360^o azimuthing Niigata ZP-41 Z-drive units. Continuously rated dual omega clutches. Z-pellers operated independently, or combined via joystick control.

Generators:
2 x 80 kW (100kVA) 380V, 50 Hz,
Alternators driven by Yanmar
6HAL2-N diesel engines.

Exhausts:
All exhausts fitted with sparkless silencers.

SPEED AND CONSUMPTION:

Service speed: 13.28 kts at 100% MCR
Consumption: 13.10 tons/day at 100% MCR
Economic Speed: 11.20 kts at 50% MCR
Consumption: 4.32 tons/day at 50% MCR

BOLLARD PULL AND TOWING EQUIPMENT :

Bollard pull:
Steady Bollard Pull at 100%
MCR 71.8T
Maximum Bollard Pull at 100%
MCR 74.0T
Bollard Pull certified by Lloyd's Register

Forward Winch:
MacGREGOR Plimsoll hydraulic anchor windlass / escort towing Winch. 65/30/4T x 5/10/65 m/min. Brake capacity 150T. Operate at winch side and wheelhouse forward console. Capacity of 120m of 100mm diameter tow rope.

Aft Towing Hook:
Towing hook of 65T SWL fitted aft of deckhouse on the upper deck with remote controlled quick release device operated from deck or the wheelhouse.

Hydraulic Power Pack:
Hydraulic pumps driven through a clutch by the port main engine.

CAPACITIES:

Clear Deck Space:
36 m²

Fuel:
166.90 m³ (100%)/160.26 m³ (96%)

Potable Water:
30 m³

Ballast:
40.5 m³ (Fresh water)

Refrigerated Storage:
Freezer: 450 litres
Cooler: 450 litres

Plus domestic fridge/freezer in the galley.

DECK MACHINERY AND EQUIPMENT:

Windlass:
2 x MacGREGOR Plimsoll Hydraulic 6T at 10 m/min windlass with 2 x 495kg AC 14 anchors. 22mm diameter anchor chain totaling 302.5m (27.5m/length x 11 lengths).

Deck Crane:
Palifinger hydraulic knuckle boom type marine crane, SWL 1.23T at 8.5m radius.

ACCOMMODATION:

Officers:	2 x 2 berth
Crew:	2 x 2 berth
	1 x 4 berth
Total:	8 berths

MISCELLANEOUS:

Tin-free antifouling paint on hull

All tanks epoxy coated (expect fuel / L.O. tanks)

Heavy duty fendering of both horizontal and vertical type with water lubrication for role as berthing tug. All round D fender with vertical stern blocks

Meters for vessel fuel consumption

Ship to ship power supply 380V AC 50Hz 100A

Two Francis Lite 300 RC searchlights on main mast and fire monitor platform

Matesaver Man overboard recovery system fitted
